Size：13000×3000×3300mm

Self-weight：1000000KG

Load capacity：40000 KG

Bottom plate：4mm pattern

Axle：Shandong Fuhua 13T*3, 3axle wheel base 2180

Suspension system：Three axle series mechanical suspension - reverse mounted suspension

Tire and Rim Factory rim, tires: 8.25R20 13pcs

Plate spring：10 pieces *90*13mm 6 sets

Brake system：Dual line braking system

Main beam material: Q345B

Main beam height: 500mm

Upper wing plate thickness: 20mm

Lower wing plate thickness: 20mm

Vertical plate thickness: 10mm

Side beam：H - beam high strength group

Ladder：Spring Mechanical ladder

Traction pin 90# and 50# interchanged

Outrigger：Yahua single action external

Spare tire rack 1

Brake system Air chamber T30/30, three 40L gas barrels

Electrical system 7 hole plug, 24 V waterproof circuit

ABS：None

Brake valve Factory

Toolbox 1 standard toolbox

Painting Chassis sand blasting rust removal, 1 layer of anti-corrosion paint, 2 layers of final paint
